Uflex UC81-OBF Front Mount Outboard Cylinder – UC81-OBF

Description

Uflex UC81-OBF Front Mount Outboard Hydraulic Steering Cylinder

The Uflex UC81-OBF Front Mount Outboard Cylinder is a high-performance hydraulic steering cylinder engineered to deliver smooth, precise, and reliable steering control for modern outboard-powered boats. Designed for front-mount outboard applications, the UC81-OBF provides efficient steering response, reduced helm effort, and exceptional durability in demanding marine environments.

Built from marine-grade, corrosion-resistant materials, the UC81-OBF is designed to withstand harsh saltwater conditions while maintaining consistent hydraulic performance. Its compact, front-mount configuration allows for clean installation on a wide range of outboard engines, making it an ideal solution for center consoles, bay boats, fishing boats, and recreational powerboats.

The UC81-OBF cylinder integrates seamlessly with Uflex hydraulic steering helms, ensuring balanced pressure, smooth tracking, and responsive control at both low speeds and high cruising speeds. Whether you’re upgrading from mechanical steering or replacing an existing hydraulic cylinder, the UC81-OBF delivers dependable performance trusted by boaters and marine professionals worldwide.

Key Performance Features

• Balanced Steering: As a balanced cylinder, it provides an equal number of turns lock-to-lock (typically 4.5 turns) in both directions, offering consistent handling and predictability.

• Split Tilt Tube Rod: Features an industry-exclusive design that allows you to install the cylinder without removing the engine, saving significant time and labor during setup or retrofitting.

• High-Pressure Reliability: Built with a 304 stainless steel main rod and machined aluminum bullhorns for enhanced durability in saltwater environments.

• Versatile Mounting: Can be installed on either the port or starboard side depending on your boat’s rigging and cowling clearance requirements.

• Easy Maintenance: Equipped with replaceable end caps, which simplify long-term servicing and extend the overall life of the unit.

Technical Specifications

• Volume: 81 cc (4.9 cu. in.)

• Output Force: 489 lbs (222 kg)

• Stroke Length: 7.3″ (186 mm)

• Max Engine Power: 115 HP

• Hose Fittings: 3/8″ high-pressure flex hose

• Bleed Fittings: DN5 quick connect for easy air purging
